FC-2600 Photoelectric Labeling Sensors Fork Shaped Sensor Suitable For Auto Packing Machine, labeling machine system

24VDC NPN NO.NC 4 Wires Push-Button Fork Optical Label Sensor


  • Brand:

    F&C
  • Item no.:

    FC-2600N/P/D
  • Payment:

    Wire transer, West Union, Paypal
  • Product origin:

    China
  • Color:

    Black
  • Goods stock:

    2000
  • Shipping port:

    Xiamen
  • Lead Time:

    3days


Overview
Quick Details
Model Number:
FC-2600
Place of Origin:
Hunan, China
Brand Name:
F&C
Usage:
package machine label sensor
Theory:
Optical sensor
Output:
Switching Transducer
Output Method:
NPN NO.NC
Detection Distance:
2.5mm
Operating temperature:
-10℃-50℃
Protection class:
IP66
Operating voltage:
12-24V VDC
Certificate:
CE
Keywords:
optical label sensor
Application:
package machine label sensor
Product name:
24VDC NPN NO.NC 4Wires Push-Button Fork Optical Label Sensor

24VDC NPN NO.NC 4 Wires Push-Button Fork Optical Label Sensor

  • Label Sensor
  • Optical Label Sensor
  • NPN Optical Label Sensor



Product Description
 F&C Main products:
Fiber Optic Sensor Fiber optic cable Proximity Sensor
Photoelectric Sensor Light Curtain Color Mark Sensor
Label sensor Magnetic Sensor Laser Alighment
Specification
Model  FC-2600
FC-2600/D

FC-2600P

FC-2600P/D

Output type NPN NO+NC PNP NO+NC
Detection distance 2.5mm
Light source  640nm red modulated light
Operating voltage DC14-24V±10%
Protection circuit Reverse polarity protection and short circuit protection
Response time <500us
Leakage current <0.01mA no-load
Operating temperature  -10℃-+50℃(without icing or condensation)
Protection degree IP66
Meterial Aluminium metal case
Wiring method

φ4mm×2M/4-wires

φ4mm×2M/M8 connector 4-wires



Advantage of fork photoelectric label sensor

1. push-button ajustment type label sensor

2.low-cost,high performance

3.Full Metal Shell,high reliability and compatibiliaty

4.0.5mm label lap can be detected

5.Pre-wired and  M8 connector label sensor availabe

More details about our sensors, welcome to contact with me by skype:lynn_liu123 and whatsapp:+8613319542018



Product Drawing





Pre-wired 2m cableType photoelectric sensor fork Label Sensor



24VDC NPN NO.NC 4 Wires Push-Button Fork Optical Label Sensor24VDC NPN NO.NC 4 Wires Push-Button Fork Optical Label Sensor

FC-2000_4-wires_NPN FC-2000_4-wires_PNP

fork label sensor wiring diagram (2)
