Brand:
OLINKItem no.:
MS3116/3112-12Payment:
Wire transer, West Union, PaypalProduct origin:
ChinaColor:
BlackShipping port:
XiamenLead Time:
7 days
1. Electrical performance: Electrical performance parameters meet high standards.
2. Environmental adaptability: Waterproof connectors have adaptability in a variety of harsh environments.
3. Size and weight: The size and weight of the connector ensure easy installation and use.
4. Mechanical properties: Our connectors have good mechanical properties, such as vibration resistance, impact resistance, plug resistance, etc.
5. Environmental sealing performance: Waterproof connectors have excellent sealing performance.
6. Life: The life of the high-specification connector can ensure that good performance and reliability can be maintained during a long time of use.
Description
|
Materials and Finishes
|
||
Shell
|
Aluminum alloy, conductive olive drab chromate over cadmium or Zinc finish QQ-P-416
|
||
Insulator
|
Polychloroprene
|
||
Grommet
|
Polychloroprene
|
||
Contacts
|
Copper alloy, gold plate per MIL-G-45204 Type II
|
Wire Range Accommodations
|
Insulation O.D. Limits
|
Contact Rating
|
|||||
Contact Size
|
AWG Wire Size
|
Min
|
Max
|
Contact Size
|
Rated Amps
|
Test Current
|
Millivolt Drop
|
20
|
24, 22, 20
|
1.52
|
2.11
|
20
|
7.5
|
7.5
|
55
|
16
|
20, 18, 16
|
1.68
|
2.77
|
16
|
22.0
|
13.0
|
49
|
12
|
12, 14
|
2.46
|
3.61
|
12
|
23.0
|
20.0
|
42
|
Operating Temperature Range
|
-55℃~125℃
|
Insulation Resistance
|
5000MΩ Min. (at 25℃)
|
Durability
|
500 cycle, mate and unmate
|
Shell Size
|
8, 10, 12, 14, 16, 18, 20, 22
|
Service Rating
|
Operating Voltaire Max.
|
Test Voltage. AC(rms), 60cps
|
||||
AC(rms)
|
DC
|
Sea Level
|
50,000(ft)
|
70,000(ft)
|
110,000(ft)
|
|
I
|
600
|
850
|
1500
|
500
|
375
|
200
|
II
|
1000
|
1275
|
2300
|
750
|
500
|
200
|
1.Industrial automation: Our connectors enable equipment in factories and industrial facilities to work in wet, dusty environments;
2.Energy field: Wind power, solar power and other new energy facilities usually need to face a variety of harsh environments, you can use our high-specification waterproof electrical connectors;
3.Rail transit: Our waterproof and dust-proof connectors can play a role in the electrical systems of subway, light rail and other rail transit facilities;
4.Communication facilities: Our high-quality electrical connectors guarantee the stable operation and safety of communication base stations, telecommunications facilities and other equipment;
Thank you for taking the time to familiarize yourself with ourMS waterproof connectorproducts. We understand the importance of selecting the appropriate connector for your project, and we are delighted by your interest in our offerings. Please do not hesitate to reach out to us as we have a wider range of similar products available. We firmly believe that these products will effectively meet your requirements while enhancing convenience and efficiency in your work.
